Cyclematic Machinery was established in 1980 in Taichung, Taiwan. The company specializes in manufacturing high-precision lathes, toolroom lathes, and CNC toolroom lathes. Renowned for its mature technology and extensive experience, Cyclematic is committed to delivering high-quality, internationally compliant precision lathes, primarily used for high-accuracy small-part machining and prototype development.
Product Highlights
In the CNC toolroom lathe market, there is no shortage of machines boasting high precision and durability. However, models that combine micron-level machining accuracy with exceptional cutting flexibility are rare. The CTL-1118CNC not only improves machining precision but also enhances productivity and adaptability through innovative tooling configurations, a smart operation interface, and a high-efficiency loading/unloading system—giving it a clear competitive edge.
High-Precision Engineering Design
Cyclematic’s CNC toolroom lathes achieve micron-level machining accuracy, a critical factor in precision part manufacturing. By replacing the traditional gearbox with a servo motor directly coupled to the leadscrew, they enhance drive efficiency and precision.
Technology Upgrade: The CTL-1118CNC Lathe
The CTL-1118CNC represents a significant advancement in Cyclematic’s product line. Built upon the durability and precision of traditional machines, it introduces an innovative tooling plate design that allows seamless switching between conventional tooling and a gang tool setup—dramatically improving machining versatility and efficiency. This reflects the company’s ability to align technical innovation with customer needs.
Quality Control and Customized Solutions
Cyclematic adheres to international quality management standards such as ISO 9001, ensuring each machine undergoes multiple precision inspections before delivery to guarantee long-term accuracy and durability. The company also offers customized machine designs tailored to the unique processing needs of different industries—a flexibility that has become a key market advantage.
Expanding International Presence
Cyclematic regularly participates in international exhibitions such as the Taipei International Machine Tool Show (TIMTOS), using these platforms to showcase the latest products and technologies while boosting brand recognition and strengthening its overseas market presence.
Design Improvements: Servo Drive & Touchscreen Interface
The adoption of a servo motor directly driving the leadscrew increases efficiency and operational flexibility. Paired with a touchscreen interface that displays spindle speed, feed rate, and other machining data in real time, this design greatly enhances operator convenience and machining stability.
CTL-1118CNC Lathe — Key Specifications & Features
Mechanical Accuracy & Structure
-Spindle roundness within 0.0015 mm
-High-precision angular contact ball bearings with pre-load for minimal backlash
-Heat-treated, ground bed for high wear resistance and rigidity
Control System
-Standard FANUC 0i Mate-TD CNC controller (optional other brands)
-Yaskawa inverter, 3 HP spindle motor (optional 5 HP)
-Balanced performance between high-speed stability and low-speed torque output
Drive & Axis System
-X/Z axis driven by AC servo motors via precision ballscrews
-Z-axis with telescopic steel covers for extended service life
Innovative Dual-Mode Cutting
-Since a 2008 redesign, the CTL-1118CNC integrates gang-tool and tailstock cutting modes in one machine.
-Gang tooling enables multiple tools on the same plane for fast multi-process cutting.
-Tailstock center supports long workpieces for precision cutting, increasing flexibility.
Ease of Operation & Loading Efficiency
-Quick-change pneumatic collet chuck system for rapid workholding
-Touchscreen interface shows spindle speed, DRO readings, threading functions, and feed rates
Machining Capacity & Dimensions
-Max swing: 380 mm
-Max bar capacity (5C collet): 27 mm
-Distance between centers: 457 mm
-Spindle speed: 50–4,000 RPM (3 HP), optional 50–6,000 RPM (5 HP)
-X-axis travel: 220 mm
-Z-axis travel: 340 mm
Optional Accessories
Gang tool plate, various chucks, and tooling systems to expand versatility.
Conclusion
The CTL-1118CNC is a major technological upgrade in Cyclematic’s toolroom lathe lineup. Combining a high-precision spindle and rigid bed structure with an advanced CNC control system and dual-mode cutting configuration (gang tooling and tailstock center), it delivers superior machining efficiency, stability, and versatility. Compared with traditional lathes, it offers significant advantages in ease of operation and loading/unloading, representing a comprehensive performance evolution.
With decades of expertise in precision toolroom lathes, Cyclematic is known for micron-level accuracy, flexible cutting configurations, and rigorous quality control. Following ISO 9001 standards, the company ensures every machine meets stringent inspection benchmarks before shipment. Backed by complete R&D, manufacturing, and customization capabilities, Cyclematic serves industries including medical devices, automotive, and aerospace. Guided by the core strategy of Precision, Flexibility, and Globalization, the company continues to lead the precision machining industry’s technological progress and global expansion.
