How Is A Slotting Machine Structured and Operated?

Slotting machines are reciprocating machines that are mainly used to manufacturing horizontal, vertical or flat surfaces.
Published: May 23, 2023
How Is A Slotting Machine Structured and Operated?

The slotting machine is actually a vertical planer, and its mechanical structure principle is similar to that of a head planer. The inserting knife moves back and forth in the vertical direction as the main movement, while the processed object is intermittently moved horizontally or on a circular arc as the feed motion. The slotting machine is mainly used for cutting planes, forming surfaces and key-ways, etc., and is suitable for single or small batch production.

Main Components of A Slotting Machine

  • Base: The base becomes a bed or box, which can support the entire slotter.
  • Cross-Slide: Install on the top of the cross-slide rail and cross-slide again.
  • Handwheel: Move the table by preliminary or horizontal rotation by operating the handwheel.
  • Column: The column is also a beam-column of the machine. It is made of cast iron and has a driving function. The column can be moved up and down by precision machining as a vertical object.
  • Ram: Carry the slotting tool and move at right angles to the table to process the workpiece.
  • Table: The table used to fix and placed the workpiece. It can be rotated in advance, horizontally or around the center to adjust to a suitable position.

Main Procesing of the Slotting Machines

  • Used to cut slots, splines key-ways for both internal and external jobs such as machining internal and external gears.
  • Used for shaping internal and external forms or profiles.
  • Used for works as machining concave, circular, semi-circular and convex surfaces.
  • Used for machining vertical surfaces, machining angular or inclined surfaces, machining of shapes which are difficult to produce on a shaper machine and machining dies and punches.
  • Used for internal machining of blind holes.
Published by May 23, 2023 Source :mechanicalengineering
